Light Eco^®

Light Eco^® Plus with Current Sensing Technology™

Light Eco^® Plus is an effective and compact energy controller designed to be installed at the electrical Distribution Board that delivers significant energy savings by controlling the amount of electricity that reaches an electromagnetically ballasted fluorescent light circuit.

How It Works

After fluorescent lights have been switched on and go through a warm up period, it is now well known and been shown in many different case studies that they can operate effectively on a reduced power supply. Light Eco^® Plus is microprocessor controlled and the improved Current Sensing Technology™ functionality ensures the unit delivers the latest in voltage reduction technology.

Extra sensitive Current Sensing Technology™ is also now programmable. Normally Light Eco^® Plus will sense the switching of 6 twin fluorescent light fittings (about 3 amps), our extra sensitive models will detect smaller loads as little as 2 twin fittings. The unit functions by allowing lights to be activated at the standard utility voltage and then reducing the voltage by switching into economy mode.  This intelligent and safe control of power reduces energy consumed with little or no impact on light output, depending on the application.

Features

With Light Eco^® Plus the savings made are easily seen: a Liquid Crystal Display panel installed on the front on the device clearly shows savings being made and the information is stored so that savings history is available for download via the optional USB port and optional software.

With improved Current Sensing Technology™, Light Eco^® Plus can sense a change in energy demand and automatically switch back to mains voltage where necessary. System wide failure is eliminated as Light Eco^® Plus automatically bypasses to mains power if overload or low voltage is detected. A bypass switch to allow manual bypass of economy mode during lighting maintenance is standard with automatic return to economy mode after a set period of time.

Models from 2.4 to 4.8 kVA are standard, whilst larger models are available. A programmable and downloadable option is available as an extra. External control of Light Eco^® Plus is possible allowing the units to be controlled by timer, daylight sensor or Building Management System. Daylight harvesting is possible using the external control facility and is the primary application with high bay lighting.

Installation

Light Eco^® Plus is connected into existing fluorescent lighting circuits and can be easily installed by an electrician in less than 30 minutes and interruption and lighting downtime is a matter of minutes.  Light Eco^® Plus is designed for retrofitting into existing installations eliminating the need for expensive modifications. Once installed there are no ongoing costs – only ongoing savings.

Warranty

Light Eco^® Plus has a standard global 3 year warranty and in all parts of the world pay for themselves in one to two years, making them an excellent investment. Not only does Light Eco^® Plus save money but it also saves the environment; Light Eco^® Plus units are manufactured in an ecologically sustainable way.

Compliance

Light Eco^® Plus also complies with the provisions of CE for the European Union (EN 55015, 60598, 60742, 61000), with AS/NZS 3350.1 for Australia & New Zealand and has the mandatory Australian Communications Authority ‘C-Tick’ approval for compliance with EMC requirements (Regd No: N1759). Light Eco^® Plus is listed with the eco-specifier knowledge base as an environmentally preferable product.

Light Eco^® Plus units are manufactured in a state of the art factory located in Sydney Australia, accredited to International Quality Standard ISO 9002.

ecoBright^® energy solutions are authorised resellers of Light Eco^® Plus in Australia and sole distributors in New Zealand and the Pacific Islands. For more information on Light Eco^® Plus direct from the manufacturer, please go to the Ilum-A-Lite website at: www.ilumalite.com
